XP3-18RT HMI&PLC 3.7" 26 Keys 192*64 DI 10 DO 8 Output Relya&Transistor with programming Cable
- Model: XP3-18RT
- Shipping Weight: 1Kg
- In Stock:12
- Manufactured by: Xinje
0 reviews
XP3-18RT HMI&PLC 3.7" 26 Keys 192*64 DI 10 DO 8 Output Relya&Transistor with programming Cable
Product description
Integrated PLC & HMI, owns the same functions as XC3 series,
3.7 inch blue LCD
Digital input:10 points/optical couple isolated
Digital output: 8 points/(relay)
Easy edit, abundant functionsv
LCD display: 192×64 pixel
use life up to 20000 hours
Functional keys up to 26
Delicacy and precise keys
Use the same cable to Compile for HMI and PLC
Compact configure, save more space
Specifications:
|
Input voltage |
DC12V-DC24V |
|
Current Consumption |
Less than 10W (TYP2.0W) |
|
Allowable Momentary Power-cut |
Less than 20ms |
|
Voltage Endurance |
AC1000V-10mA 1 minute (signal and ground) |
|
Insulated Resistance |
DC500V-about 10M OHM (signal and ground) |
|
Operation Temperature |
0~50degree centigrade |
|
Storage Temperature |
–10~60degree centigrade |
|
Ambient Humidity |
20~85%(Non-condensing, dry bulb) |
|
Vibration Resistance |
10~25Hz (X,Y,Z directions for 30 minutes 2G) |
|
Interference Rejection |
Noise voltage: 1000Vp-p |
|
Atmosphere |
Free of corrosive gas |
|
Protect Configuration |
IP65F |
