K523-08DR Kinco PLC Extension IO module DI 4 DO 4 relay output new in box
- Model: K523-08DR
- Shipping Weight: 1Kg
- In Stock:20
- Manufactured by: Kinco
0 reviews
| K523-08DR Kinco PLC Extension IO module DI 4 DO 4 relay output new in box |
Specification
|
Input point |
4, totally classified into 1 group |
|
Input type |
Source(common-cathode)/sink(common-anode) |
|
Input voltage |
Rated DC24V, voltage range of logic “1” is DC11-30V |
|
Output point |
4, totally classified into 1 group |
|
Output type |
Relay |
|
Load voltage |
Max. DC30V/AC250V, max. load current of each channel is 2A |
|
Isolation mode |
DI channels adopt opto-electrical isolation DO channels adopt relay isolation |
|
Signal indication |
Separated LED indicates for each channel |
|
Module width |
50mm |
