CPU module

CPU504

K504-14AT

-       Supply power: AC130-265V

-       DI 8*DC24V, DO 6*DC24V

-       1 RS232 port, without expansion

K504-14AR

-       Supply power: AC130-265V

-       DI 8*DC24V, DO 6*Relay

-       1 RS232 port, without expansion

CPU504EX

K504EX-14AT

-       Supply power: AC130-265V

-       DI 8*DC24V, DO 6*DC24V

-       2 serial communication ports(1*RS232, 1*RS485)

K504EX-14AR

-       Supply power: AC130-265V

-       DI 8*DC24V, DO 6*Relay

-       2 serial communication ports(1*RS232, 1*RS485)

CPU506

K506-24AT

-       Supply power: AC85-265V

-       DI 14*DC24V, DO10*DC24V

-       3 serial communication ports(1*RS232, 2*RS485)

K506-24AR

-       Supply power: AC85-265V

-       DI 14*DC24V, DO10*Relay

-       3 serial communication ports(1*RS232, 2*RS485)

CPU506EA

K506EA-30AT

-       Supply power: AC85-265V

-       DI 14*DC24V, DO10* DC24V, AI 4*IV,AO 2*IV

-       3 serial communication ports(1*RS232, 2*RS485)

CPU508

K508-40AT

-       Supply power: AC85-265V

-       DI 14*DC24V, DO16* DC24V

-       3 serial communication ports(1*RS232, 2*RS485)

K508-40AX

-       Supply power: AC85-265V

-       DI 14*DC24V, DO4*DC24V + 12*Relays

-       3 serial communication ports(1*RS232, 2*RS485)

K508-40AR

-       Supply power: AC85-265V

-       DI 14*DC24V, DO16*Relay

-       3 serial communication ports(1*RS232, 2*RS485)

Expansion IO modules

PM521

K521-08DX

-       DI 8*DC24V

K521-16DX

-       DI 16*DC24V

PM522

K522-08XR

-       DO 8*Relay

K522-16XR

-       DO 16*Relay

K522-08DT

-       DO 8*DC24V

K522-16DT

-       DO 16*DC24V

PM523

K523-16DR

-       DI 8*DC24V,DO 8*Relay

K523-08DR

-       DI 4*DC24V,DO 4*Relay

K523-16DT

-       DI 8*DC24V, DO 8*DC24V

K523-08DT

-       DI 4*DC24V, DO 4*DC24V

PM531

K531-04IV

-       4 analog input channels, 4-20mA/1-5V/0-20mA/0-10V

K531-04RD

-       4 RTD input channels

-       2/3 wire optional for each channel

-       PT100/PT1000/Cu50

PM532

K532-02IV

-       2 analog output channels, 4-20mA/1-5V/0-20mA/0-10V

PM533

K533-04IV

-       2 analog input channels, 4-20mA/1-5V/0-20mA/0-10V

-       2 analog output channels, 4-20mA/1-5V/0-20mA/0-10V

Expansion function modules

SM541

K541

-       CAN communication module, supports CANopen main station and free CAN communication
