AFPX0L40R-F FP-X0 L40R PLC Expansion unit 24 VDC DI 24 Transistor DO 4 Relay DO 12 new
- Model: AFPX0L40R-F
- Shipping Weight: 1.5Kg
- In Stock:20
- Manufactured by: Panasonic
|AFPX0L40R-F FP-X0 L40R PLC Expansion unit 24 VDC DI 24 Transistor DO 4 Relay DO 12 new|
High speed : 3000 steps to the following basic instruction0.08 U S / step,3001
step above the basic instruction0.58 U S / step function: relay + transistor hybrid output, may correspond to a variety of demand. Pulse output maximum 50KHz x 2CH,
maximum 50KHz x 4CH high speed counter. Built-in 2CH analog input ( voltage, potentiometers, thermistor input selectable ). ( the built-in calendar clock (2) equipped with a programming port (RS232C ), COM ( RS485).
(3) the program capacity: L14R / L30R2.5K; L40R / L60R / L40MR / L60MR8K I / O
points of maximum216 points a control unit can be continuously extended up to3 FPX
expansion unit, if you want to further expand the words, can also use FP0expansion unit
