ATV12HU22M2 VFD Inverter Input 1ph 220V Output 3ph 220~240V 10A 0.5~400Hz 2.2KW 3HP NEW
- Model: ATV12HU22M2
- Shipping Weight: 3Kg
- In Stock:30
- Manufactured by: Schneider
0 reviews
| ATV12HU22M2 VFD Inverter Input 1ph 220V Output 3ph 220~240V 10A 0.5~400Hz 2.2KW 3HP NEW |
|
Schneider Altivar 12 variable speed drives used for 3-Phase motors from 0.18 to 4kw.
The Altivar 12 is well-suited for use in applications involving simple industrial machines or certain consumer machines. Its compact size, high performance and discreet appearance make it particularly attractive for use in the following sectors:
1. Food industry (ventilation of catering kitchens, bagging machines, bakers’ kneading machines, greenhouses, etc.
2. Small handing Applications (car washes, conveyors,etc.)
3. Medical and health sector (medical beds, fitness machines)
4. Machines with a single-phase socket (wood-working machines, surface polishing and cleaning machines, swimming pool or irrigation pumps, hydro massage bathtubs, etc)
5. New markets (solar applications, etc.)
|
Motor |
Line supply (input) |
Drive (output) |
Reference |
||||||
|
Power indicated on plate |
Maximum line current |
Apparent power |
Power dissipated at nominal current |
Nominal current In |
Max. transient current for |
||||
|
at 100 V |
at 120 V |
60 s |
2 s |
||||||
|
kW |
HP |
A |
A |
kVA |
W |
A |
A |
A |
|
|
0.18 |
0.25 |
6 |
5 |
1 |
18 |
1.4 |
2.1 |
23 |
ATV12H018F1 |
|
0.37 |
0.5 |
11.4 |
9.3 |
1.9 |
29 |
2.4 |
3.6 |
4 |
ATV12H037F1 |
|
0.75 |
1 |
18.9 |
15.7 |
3.3 |
48 |
4.2 |
6.3 |
6.9 |
ATV12H075F1 |
For three Phase Output 200/240 V motors
|
Motor |
Line supply (input) |
Drive (output) |
Reference |
||||||
|
Power indicated on plate |
Maximum line current |
Apparent power |
Power dissipated at nominal current |
Nominal current In |
Max. transient current for |
||||
|
at 200 V |
at 240 V |
60 s |
2 s |
||||||
|
kW |
HP |
A |
A |
kVA |
W |
A |
A |
A |
|
|
0.18 |
0.25 |
3.4 |
2.8 |
1.2 |
18 |
1.4 |
2.1 |
2.3 |
ATV12H018M2 |
|
0.37 |
0.5 |
5.9 |
4.9 |
2 |
27 |
2.4 |
3.6 |
4 |
ATV12H037M2 |
|
0.55 |
0.75 |
8 |
6.7 |
2.8 |
34 |
3.5 |
5.3 |
5.8 |
ATV12H055M2 |
|
0.75 |
1 |
10.2 |
8.5 |
3.5 |
44 |
4.2 |
6.3 |
6.9 |
ATV12H075M2 |
|
1.5 |
2 |
17.8 |
14.9 |
6.2 |
72 |
7.5 |
11.2 |
12.4 |
ATV12HU15M2 |
|
2.2 |
3 |
24 |
20.2 |
84 |
93 |
10 |
15 |
16.5 |
ATV12HU22M2 |
